如下为我司爱泽工业IZE_Industries本月到货CARLO GAVAZZI相关产品，欢迎致电索取样本资料和产品信息。
CARLO GAVAZZI功率变送器CPTDINAV53LA1AX CARLO GAVAZZI继电器DIB01CB2310A
CARLO GAVAZZI继电器DPB01CM48 CARLO GAVAZZI继电器DPB51CM44
CARLO GAVAZZI继电器RAM1A60D50Z CARLO GAVAZZI继电器RM1A48D75
CARLO GAVAZZI继电器RZ3A40D55 CARLO GAVAZZI模块SPD241203
CARLO GAVAZZI功率变送器CPT-DIN系列介绍
紧凑型三相功率变送器，特别适用于测量各类电气参数，也适用于机械设备内部安装。采用DIN导轨安装外壳，可选配最多3路模拟量输出、RS485通信接口、报警输出或“Dupline"总线接口。各项参数均可通过UCS软件进行编程设置。
3-phase compact power transducer. Particularly recommended for the measurement of the main electrical variables also on board of machines. Housing for DIN-rail mounting, with up to 3 analogue outputs, or RS485 communication port or alarm outputs or “Dupline" bus. Parameters programmable by means of UCS software.
CARLO GAVAZZI监控继电器DIB01系列介绍
DIB01和PIB01是高精度的 TRMS（真有效值）交直流过流或欠流（可通过 DIP 开关选择）监控继电器。支持直接测量或通过电流互感器测量。凭借内置的锁存功能，继电器输出可保持在“接通"状态。利用禁止功能，可在不需要继电器动作时（如维护或系统转换期间）防止其动作。LED 指示灯用于显示报警及输出继电器的状态。通过内置分流器，可监控高达 10 A 的交直流负载。
• TRMS 交直流过流或欠流监控继电器
• 通过内部分流器进行电流测量
• 通过 DIP 开关选择测量范围
• 测量范围：0.1 mA 至 10 A（交直流）
• 电流设定值可调（相对刻度）
• 迟滞值可调（相对刻度）
• 延时功能可调（0.1 至 30 秒）
• 可编程设定锁存或禁止功能
• 输出：8 A SPDT（单刀双掷）继电器，支持选择常断（N.D.）或常通（N.E.）模式
• 安装方式：符合 DIN/EN/IEC 60715 标准的 DIN 导轨安装（DIB01）或插入式模块（PIB01）
• 外壳规格：22.5 mm 欧标外壳（DIB01）或 36 mm 插入式模块（PIB01）
• LED 指示：继电器状态、报警状态及电源接通状态
• 电气隔离电源
DIB01 and PIB01 are precise TRMS AC/DC over or under current (selectable by DIP switch) monitoring relays. Direct measuring or through current transformer. Owing to the built-in latch function, the ON-position of the relay output can be maintained. Inhibit function can be used to avoid relay operation when not desired (maintenance, transitions). The LED’s indicate the state of the alarm and the output relay. Through the built-in shunt it is possible to mon itor loads up to 10 A AC/DC.
• TRMS AC/DC over or under current monitoring relay
• Current measuring through internal shunt
• Selection of measuring range by DIP-switches
• Measuring ranges from 0.1 mA to 10 A AC/DC
• Adjustable current on relative scale
• Adjustable hysteresis on relative scale
• Adjustable delay function (0.1 to 30 s)
• Programmable latching or inhibit at set level
• Output: 8 A SPDT relay N.D. or N.E. selectable
• For mounting on DIN-rail in accordance with DIN/EN/EC 60715 (DIB01) or plug-in module (PIB01)
• 22.5 mm Euronorm housing (DIB01) or 36 mm plug-in module (PIB01)
• LED indication for relay, alarm and power supply ON
• Galvanically separated power supply
CARLO GAVAZZI监控继电器DPB系列介绍
DPB01和PPB01是三相电网监测继电器。它们适用于三相（3P）及三相加中性线（3P+N）系统，可监测缺相、相序（型号后缀为“N"的版本不具备此功能）以及过压和欠压状况。设备由被监测的电网供电。针对过压/欠压报警，设有最长 30 秒的报警延时功能。
• 监测三相三线（3P）或三相四线（3P+N）电网。
• 检测相序是否正确（型号后缀为“N"的版本不具备此功能）及是否存在缺相。
• 过压和欠压设定值可通过面板旋钮调节。
• 具备延时功能。
• 转换触点继电器输出。
DPB01 and PPB01 are 3-phase mains monitoring relays. They operate on 3P and 3P+N systems, monitoring phase loss and phase sequence (not present in versions with "N ending), over voltage and under voltage. Power supply provided by the monitored mains. Delay on alarm, up to 30 s, for over/under voltage alarms.
• Monitoring 3-phase mains with 3 wires (3P) or 4 wires (3P+N).
• Detection of the correct phase sequence (not present in versions with "N" ending) and phase loss.
• Front dial adjustable over voltage and under voltage set points.
• Time delay.
• Changeover relay output.
CARLO GAVAZZI继电器RAM1A系列介绍
这种采用反并联晶闸管输出的单极工业继电器，因其广泛的应用场景而成为常用的工业级固态继电器（SSR）。该继电器适用于阻性负载及轻微感性负载。过零触发型继电器在正弦波过零点时导通，并在电流过零点时关断。具有直流控制输入的瞬时导通型继电器可用于相位角控制。内置的阻容（RC）吸收电路可提供瞬态保护。LED 指示灯用于显示控制输入状态。卡扣式防护盖可确保防触电安全（防护等级 IP20）。
• 交流开关固态继电器
• 直接覆铜（DCB）技术
• 反并联晶闸管输出
• 获 VDE 认证
• 控制信号指示 LED
• 卡扣式 IP20 防护盖
• 自升式接线端子
• 65 kA UL 短路电流额定值
The industrial, 1-pole relay with antiparallel thyristor output is the most widely used industrial SSR due to its multiple application possibilities. The relay can be used for resistive and slightly inductive loads. The zero switching relay switches ON when the sinusoidal curve crosses zero and switches OFF when the current crosses zero. The instant on relay with DC control input can be used for phase angle control. The built-in snubber secures transient protection. The LED indicates the status of the control input. The clip on cover secures touch protection (IP 20).
• AC switching Solid State Relay
• Direct copper bonding (DCB) technology
• Back to Back thyristor output
• VDE certified
• LED for control presence indication
• Clip-on IP20 protection cover
• Self-lifting terminals
• 65 kA UL short circuit current rating
CARLO GAVAZZI继电器RM系列介绍
这种采用反并联晶闸管输出的工业级单相继电器，因其广泛的适用性而成为应用普遍的工业固态继电器（SSR）。该继电器适用于阻性、感性和容性负载。过零触发型继电器在正弦波过零点时导通，并在电流过零点时关断。具有直流控制输入的瞬时导通型继电器可用于相位控制。内置压敏电阻为重工业应用提供瞬态保护，LED指示灯显示控制输入状态。卡扣式防护盖确保了IP 20等级的防触电保护。带防护功能的输出端子可连接截面积最大为16mm²的导线。
• 交流固态继电器：过零触发型 (RM1A) 或瞬时导通型 (RM1B)
• 直接覆铜 (DCB) 技术
• LED状态指示
• 内置压敏电阻
• 卡扣式IP 20防护盖
• 自升式端子
• 无灌封胶外壳设计
• 2种输入范围：3-32* VDC 和 20-280VAC/22-48VDC
• 额定工作参数：最高 100AACrms 和 600VACrms
• 阻断电压：最高 1400Vp
• 光电隔离：> 4000VACrms
The industrial, 1-phase relay with antiparallel thyristor output is the most widely used industrial SSR due to its multiple application possibilities. The relay can be used for resistive, inductive and capacitive loads. The zero switching relay switches ON when the sinusoidal curve crosses zero and switches OFF when the current crosses zero. The instant-on relay with DC control input can be used for phase control. The built in varistor secures transient protection for the heavy industrial applications, and the LED indicates the status of the control input. The clip-on cover is securing touch protection to IP 20. Protected output terminals can handle cables up to 16mm2.
• Zero switching (RM1A) or instant-on switching (RM1B) AC Solid State Relay
• Direct copper bonding (DCB) technology
• LED indication
• Built-in varistor
• Clip-on IP 20 protection cover
• Self-lifting terminals
• Housing free of moulding mass
• 2 input ranges: 3-32* VDC and 20-280VAC/22-48VDC
• Operational ratings: Up to 100AACrms and 600VACrms
• Blocking voltage: Up to 1400Vp
• Opto-isolation: > 4000VACrms
CARLO GAVAZZI继电器RZ3A系列介绍
RZ3A是一款三相三极开关型固态继电器，适用于加热元件、电机和变压器等各种工业负载。
该系列涵盖多种负载电流规格，最高可达 75 AAC。最大额定电流取决于固态继电器所安装的散热器尺寸。输出端配有集成压敏电阻，可提供过压保护。绿色 LED 指示灯用于显示控制导通状态。
RZ3A..P 型号可选配集成过温保护功能，可防止固态继电器输出端因过热而损坏。一旦发生过热，系统将激活 LED 指示并输出报警信号，以便进行远程监控。
• 过零开关型三相固态继电器
• 额定参数最高达 690 VAC、75 AAC
• 高阻断电压
• 直流 (DC) 或交流 (AC) 控制电压
• 集成过压保护
• 可选过温保护功能及报警输出
• 控制输入及过温报警状态 LED 指示
• 具备 UL 认证的电机额定参数
The RZ3A is a 3-phase, 3-pole switching solid state relay suitable for various industrial loads such as heating elements, motors and transformers.
The series covers a range of load currents, up to 75 AAC. The maximum current rating depends on the size of the heatsink to which the solid state relay is mounted. The output is protected against over voltages by means of an integrated varistor. Control ON indication is provided through a green LED.
The RZ3A..P optionally provides integrated over temperature protection that will protect the solid state relay output against damage from overheating. In case of overheating, an LED indication and alarm output is activated for remote signaling.
• Zero cross switching 3-phase solid state relay
• Ratings up to 690 VAC, 75 AAC
• High blocking voltage
• DC or AC control voltage
• Integrated over voltage protection
• Over-temperature protection option with alarm output
• LED indication of control input and over-temperature alarm status
• UL certified motor ratings
CARLO GAVAZZI常用型号：
CARLO GAVAZZI CPTDINAV51HA1AX
CARLO GAVAZZI CPTDINAV51HA3AX
CARLO GAVAZZI CPTDINAV51HO2AX
CARLO GAVAZZI CPTDINAV51HR2AX
CARLO GAVAZZI CPTDINAV51HS1AX
CARLO GAVAZZI CPTDINAV51HS2AX
CARLO GAVAZZI CPTDINAV51HV1AX
CARLO GAVAZZI CPTDINAV51HV3AX
CARLO GAVAZZI CPTDINAV51LA1AX
CARLO GAVAZZI CPTDINAV51LA3AX
CARLO GAVAZZI CPTDINAV51LO2AX
CARLO GAVAZZI CPTDINAV51LR2AX
CARLO GAVAZZI CPTDINAV51LS1AX
CARLO GAVAZZI CPTDINAV51LS2AX
CARLO GAVAZZI CPTDINAV51LV1AX
CARLO GAVAZZI CPTDINAV51LV3AX
CARLO GAVAZZI CPTDINAV53HA1AX
CARLO GAVAZZI CPTDINAV53HA3AX
CARLO GAVAZZI CPTDINAV53HO2AX
CARLO GAVAZZI CPTDINAV53HR2AX
CARLO GAVAZZI CPTDINAV53HS1AX
CARLO GAVAZZI CPTDINAV53HS2AX
CARLO GAVAZZI CPTDINAV53HV1AX
CARLO GAVAZZI CPTDINAV53HV3AX
CARLO GAVAZZI CPTDINAV53LA1AX
CARLO GAVAZZI CPTDINAV53LA3AX
CARLO GAVAZZI CPTDINAV53LO2AX
CARLO GAVAZZI CPTDINAV53LR2AX
CARLO GAVAZZI CPTDINAV53LS1AX
CARLO GAVAZZI CPTDINAV53LS2AX
CARLO GAVAZZI DIB01CB2310A
CARLO GAVAZZI DIB01CB23500MA
CARLO GAVAZZI DIB01CB2350MA
CARLO GAVAZZI DIB01CB235A
CARLO GAVAZZI DIB01CB235MA
CARLO GAVAZZI DIB01CD4810A
CARLO GAVAZZI DIB01CD48500MA
CARLO GAVAZZI DIB01CD4850MA
CARLO GAVAZZI DIB01CD485A
CARLO GAVAZZI DIB01CD485MA
CARLO GAVAZZI DIB01CM24100A
CARLO GAVAZZI DIBO1CB2310A
CARLO GAVAZZI DPB01CM23
CARLO GAVAZZI DPB01CM23N
CARLO GAVAZZI DPB01CM44
CARLO GAVAZZI DPB01CM48
CARLO GAVAZZI DPB01CM48N
CARLO GAVAZZI DPB01CM48NW4
CARLO GAVAZZI DPB01CM48W4
CARLO GAVAZZI DPB02CM23
CARLO GAVAZZI DPB02CM44
CARLO GAVAZZI DPB02CM48
CARLO GAVAZZI DPB51CM44
CARLO GAVAZZI DPB52CM44
CARLO GAVAZZI RAM1A23D25Z
CARLO GAVAZZI RAM1A23D50
CARLO GAVAZZI RAM1A23D50G
CARLO GAVAZZI RAM1A23D75
CARLO GAVAZZI RAM1A60A100G
CARLO GAVAZZI RAM1A60A125
CARLO GAVAZZI RAM1A60A125G
CARLO GAVAZZI RAM1A60A25
CARLO GAVAZZI RAM1A60A25G
CARLO GAVAZZI RAM1A60A25Z
CARLO GAVAZZI RAM1A60A51G
CARLO GAVAZZI RAM1A60A75
CARLO GAVAZZI RAM1A60D100
CARLO GAVAZZI RAM1A60D100G
CARLO GAVAZZI RAM1A60D100Z
CARLO GAVAZZI RAM1A60D125
CARLO GAVAZZI RAM1A60D125Z
CARLO GAVAZZI RAM1A60D25
CARLO GAVAZZI RAM1A60D25Z
CARLO GAVAZZI RAM1A60D50
CARLO GAVAZZI RAM1A60D50G
CARLO GAVAZZI RAM1A60D50Z
CARLO GAVAZZI RAM1A69A125
CARLO GAVAZZI RAM1A69D100
CARLO GAVAZZI RM1A23A100
CARLO GAVAZZI RM1A23A25
CARLO GAVAZZI RM1A23A50
CARLO GAVAZZI RM1A23A75
CARLO GAVAZZI RM1A23D100
CARLO GAVAZZI RM1A23D25
CARLO GAVAZZI RM1A23D50
CARLO GAVAZZI RM1A23D75
CARLO GAVAZZI RM1A40A100
CARLO GAVAZZI RM1A40A25
CARLO GAVAZZI RM1A40A50
CARLO GAVAZZI RM1A40A75
CARLO GAVAZZI RM1A40D100
CARLO GAVAZZI RM1A40D25
CARLO GAVAZZI RM1A40D50
CARLO GAVAZZI RM1A40D75
CARLO GAVAZZI RM1A48A100
CARLO GAVAZZI RM1A48A25
CARLO GAVAZZI RM1A48A50
CARLO GAVAZZI RM1A48A75
CARLO GAVAZZI RM1A48D100
CARLO GAVAZZI RM1A48D25
CARLO GAVAZZI RM1A48D50
CARLO GAVAZZI RM1A48D75
CARLO GAVAZZI RM1A60A100
CARLO GAVAZZI RM1A60A25
CARLO GAVAZZI RM1A60A50
CARLO GAVAZZI RM1A60A75
CARLO GAVAZZI RM1A60D100
CARLO GAVAZZI RM1A60D25
CARLO GAVAZZI RM1A60D50
CARLO GAVAZZI RM1A60D75
CARLO GAVAZZI RZ3A40A25
CARLO GAVAZZI RZ3A40A55
CARLO GAVAZZI RZ3A40A55P
CARLO GAVAZZI RZ3A40A75
CARLO GAVAZZI RZ3A40A75P
CARLO GAVAZZI RZ3A40D25
CARLO GAVAZZI RZ3A40D25P
CARLO GAVAZZI RZ3A40D55
CARLO GAVAZZI RZ3A40D55P
CARLO GAVAZZI RZ3A40D75
CARLO GAVAZZI RZ3A40D75P
CARLO GAVAZZI RZ3A48D25
CARLO GAVAZZI RZ3A48D55
CARLO GAVAZZI RZ3A48D75
CARLO GAVAZZI RZ3A60A25
CARLO GAVAZZI RZ3A60A55
CARLO GAVAZZI RZ3A60A55P
CARLO GAVAZZI RZ3A60A75
CARLO GAVAZZI RZ3A60A75P
CARLO GAVAZZI RZ3A60D25
CARLO GAVAZZI RZ3A60D25P
CARLO GAVAZZI RZ3A60D55
CARLO GAVAZZI RZ3A60D55P
CARLO GAVAZZI RZ3A60D75
CARLO GAVAZZI RZ3A60D75P
CARLO GAVAZZI RZ3A69A75
CARLO GAVAZZI RZ3A69D75
CARLO GAVAZZI SPD05181
CARLO GAVAZZI SPD121203
CARLO GAVAZZI SPD241002
CARLO GAVAZZI SPD241203
CARLO GAVAZZI SPD242403
CARLO GAVAZZI SPD244803
CARLO GAVAZZI SPD24901L
CARLO GAVAZZI SPD249603
如果您需要完整的CARLO GAVAZZI的相关技术咨询，请随时致电爱泽工业，或者访问网站,我们将尽全力解决您的问题。
If you have any question for CARLO GAVAZZI，Please feel free to communicate with us and we will do our best to solve your problem.
